An Analog Signature Analysis System is connected to a PC which can save "signatures" from an entire board.
For any type of component, the system learns and saves "signatures"
which can be compared automatically with those of another PCB.
This also allows for discontinued and obsolete boards to be saved for future reference.
Latest Shop Creation ~ In or Out of Circuit Component Checker
USB Curve Tracer for Windows PC with 4ma/40ma/400ma ranges
Also with gate/base driver to turn on and test Transistors/etc while the devices are still in the Board or Unit
*Note - USB Curve Tracer Units are not for sale.
